Could You Actually Build a Stillsuit? A Sober Look at the Physics of Wearing Your Own Water Supply

I’ve read Dune two times, and the object that has always fascinated me more than the sandworms is the stillsuit. It’s the least dramatic piece of technology in the book and, to an engineer, the most interesting: a garment that recycles your own body’s water so efficiently that you can cross a desert on almost nothing. So I set myself a question over half-term: could you build one? Not “could you build something suit-shaped,” but could you hit the actual performance the book claims?

I went in with a hypothesis because a question without one is just daydreaming. My bet was: the water-recovery chemistry is basically solved — we already do it in spacecraft — but the energy and heat budget is the true wall. By the end, I still think that’s roughly right, but I was wrong about the emphasis in a way that surprised me, and I’ll get to that.

The fictional spec

In Herbert’s world, the Fremen stillsuit is a multilayer garment that reclaims the water in your sweat and breath, filters it, and feeds it back to you through a tube. Even urine and faeces get processed in the thigh pads. The famous claim comes from Stilgar: a properly fitted, well-functioning suit loses you no more than a thimbleful of moisture a day. That’s the number to beat. A thimbleful is roughly 2–5 mL. Hold that figure in your head, because everything below is really about how far real physics lands from it.

Breaking the body’s water budget into streams

Before recovering water, you have to know how much you’re losing and through which channels. In a hot environment, there are three streams.

Sweat is the giant. It dwarfs everything else. According to the US National Academies’ volume Nutritional Needs in Hot Environments, maximal sweating capacity runs from about 1.5 litres per hour in an unacclimatised person to 2–3 litres per hour in a heat-acclimatised individual, and sweat losses can reach as much as 10 litres per day under heavy heat stress. Even at a moderate desert-walking pace, losing a litre an hour is entirely realistic.

Respiration is smaller and sneakier. Every breath you exhale is nearly saturated with water vapour that you had to donate from your own tissues. At rest, respiratory water loss is about 400 mL/day, but it scales with how hard you’re breathing — one study found exhaled-water loss rising to around 60–70 mL/hour at a heart rate of 140 bpm. Call it 0.5–1.5 L/day when you’re active.

Urine is the one the body can throttle. Your kidneys must pass a minimum volume to flush nitrogenous waste — the obligatory minimum is about 500 mL/day, and in the short term a healthy young adult can concentrate down to roughly 200 mL/day. You can’t go to zero without poisoning yourself.

Add it up, and an active human in a desert is haemorrhaging water on the order of several litres a day, of which sweat is 80–90%. Any suit that matters has to win the sweat battle.

Stream by stream: the technology that already recovers each

Here’s where my hypothesis started looking strong, because for each stream there’s real, working hardware.

Breath and sweat → condensation and sorbent capture. The elegant version of this is atmospheric water harvesting with metal–organic frameworks (MOFs) - crystalline sponges so porous that a single gram has the surface area of a football pitch. In the headline 2017 paper, Kim, Yaghi, Wang and colleagues (Science 356, 430–434) reported a MOF-801 device that captured 2.8 litres of water per kilogram of MOF per day at just 20% relative humidity, driven by nothing but sunlight. That “even at low humidity” part is exactly the desert problem, so this looked like a direct hit. Inside a sealed suit the humidity from your own breath and sweat would be far higher than 20%, which should make capture easier.

Urine → distillation and membrane filtration. Dirty water into clean water is old chemistry. You can boil it and re-condense the vapour (distillation), or push it through semi-permeable membranes under pressure (reverse osmosis) or across a vapour gap (membrane distillation). All are mature.

The proof it can all be closed: the ISS. This is the part that genuinely impressed me. NASA’s Environmental Control and Life Support System reclaims about 98% of the water astronauts bring aboard — and yes, that explicitly includes breath, sweat, and urine. Cabin dehumidifiers capture exhaled and perspired moisture; the Urine Processor Assembly recovers water from urine by vacuum distillation; and a newer Brine Processor Assembly, which uses membrane distillation on the leftover brine, pushed total recovery from 93–94% up to that 98% figure. A stillsuit is, functionally, a wearable ECLSS. So the loop can be closed. On the chemistry, I was right.

The wall: energy and heat

And then you try to make it wearable, silent, and desert-ready, and the whole thing runs into thermodynamics.

First problem: condensing water costs energy — or rather, it dumps heat. To turn water vapour back into liquid you have to remove its latent heat, which for water is about 2.26 MJ/kg at 100 °C, rising to roughly 2.4 MJ/kg at skin temperature. That works out to around 0.63–0.68 kWh of heat per litre condensed. That heat doesn’t vanish; it has to be rejected somewhere. In a desert, “somewhere” is the problem.

Second problem, and the one I underrated: the wearer is a 100-watt heater. A resting human dissipates about 100 W of metabolic heat — the same as an old incandescent bulb, ~2,000 kcal/day — and during hard exertion that climbs past 1,000 W. On a normal day your body sheds this heat partly by radiation and convection to cooler air, and partly by evaporating sweat.

Now watch the trap close. In a desert, the air is often hotter than your skin (skin sits near 35 °C; midday desert air can be 45 °C+). When ambient temperature exceeds skin temperature, radiation and convection run backwards — the environment heats you. Under those conditions, evaporating sweat is the only passive way left to dump heat. But a stillsuit’s entire purpose is to stop that sweat from evaporating into the desert and recapture it instead. The suit’s core function directly sabotages the body’s last remaining cooling mechanism. That’s the insight that flipped my thinking: the stillsuit isn’t just an energy problem, it’s a self-defeating loop. Saving the water means keeping the heat.

So how do you cool the wearer? Three options, none good:

• Evaporative cooling works beautifully — it’s what your body already does — but it throws away the water you’re trying to hoard. Self-defeating by definition.

• Passive radiative cooling is real and clever: Stanford’s Raman, Fan and colleagues (Nature 515, 540–544) built a surface that sits ~4.9 °C below ambient in full sun by beaming heat to space through an atmospheric infrared window, at about 40 W/m². But 40 W/m² is modest, it needs clear sky access, and it can’t shift a 100 W load, let alone a 1,000 W one, from the small area of a person.

• Active refrigeration is the only thing that can pump heat “uphill” from a warm body into hotter air. In a wearable form, that means thermoelectric (Peltier) coolers — solid-state, silent, no moving parts, very stillsuit-appropriate. The catch is efficiency. A real Peltier cooler manages a coefficient of performance around 0.69, versus ~2.6 for the compressor in your fridge, and the peer-reviewed ceiling is unforgiving: because the material figure of merit ZT sits near 1, thermoelectrics realistically reach only about 40% of the ideal Carnot performance.

Let me put rough numbers on it (these are my own back-of-envelope estimates, so treat them as estimates). To pump just the 100 W resting load out of the suit with a Peltier at COP ≈ 0.5, you’d spend ~200 W of electrical power — and that 200 W also turns into heat on the hot side, so you’re now trying to reject ~300 W into 45 °C air. Run something like that continuously and you’re looking at very roughly 5 kWh per day of electrical energy just for thermal management, before you power any pumps or sorbent cycles. Lithium-ion stores about 0.2–0.25 kWh/kg, so that’s on the order of 20 kg of battery strapped to someone already overheating. And the moment they exert themselves and hit 500+ W of metabolic heat, the numbers blow up entirely.

Verdict

So, back to my hypothesis. I said the recovery chemistry was solved and the energy/heat budget was the wall. I’d now put it more precisely.

Water recovery is solved in principle but weaker in practice than the lab implies. The ISS proves you can close the loop to 98%. But the honest desert data humbled me: when Yaghi’s team took their MOF harvester out of the lab and into the Arizona desert, it produced not 2.8 L/kg/day but about 0.1 L/kg/day — roughly a 28-fold drop from bench to real arid air. Newer active devices that blow air over the sorbent have since reached 3.5 L/kg/day at 17–32% humidity, which is genuinely promising — but “active” means fans, power, and complexity. Inside a suit you’re recapturing your own high-humidity breath rather than mining dry desert air, which helps; even so, “solved” deserves an asterisk.

The real wall is heat rejection, not water chemistry — and it’s nastier than a plain energy budget. An energy budget is “merely” an engineering constraint: give me a big enough power source and I can run any pump. But dumping 100+ watts from a body into air hotter than that body, while simultaneously refusing to let it sweat, is close to a genuine thermodynamic corner. You’re forced into active heat pumping, which spends large electrical power, which generates yet more heat you must also reject. That feedback is the true stillsuit-killer, and Herbert’s book quietly ignores it.

Does any of it violate physics outright? No — and that’s worth saying clearly. A powered, refrigerated, water-recovering garment breaks no laws; NASA’s spacesuits already do active thermal control and water recovery. What breaks is the specific Dune promise: a silent, passive, lightweight suit that loses a thimbleful a day while you march across dunes. The thimbleful is the fantasy. Strip the poetry away and you’re left with a small backpack refrigerator wearing a person — which is real, but is not a stillsuit.

If I were actually to attempt this as a project, I now know where I’d spend my effort: not on the recovery membranes, which basically work, but on the heat-rejection stage, because that’s the load-bearing wall. That reversal — expecting the chemistry to be the hard part and finding the heat was — is the thing I’ll take away from the exercise.

---

Sources

• H. Kim, S. Yang, S. R. Rao, S. Narayanan, E. A. Kapustin, H. Furukawa, A. S. Umans, O. M. Yaghi, E. N. Wang, “Water harvesting from air with metal-organic frameworks powered by natural sunlight,” Science 356, 430–434 (2017). DOI: 10.1126/science.aam8743 — https://www.science.org/doi/10.1126/science.aam8743

• F. Fathieh, M. J. Kalmutzki, E. A. Kapustin, P. J. Waller, J. Yang, O. M. Yaghi, “Practical water production from desert air,” Science Advances 4, eaat3198 (2018). DOI: 10.1126/sciadv.aat3198 — https://www.science.org/doi/10.1126/sciadv.aat3198

• “Environmentally adaptive MOF-based device enables continuous self-optimizing atmospheric water harvesting,” Nature Communications 13, 5406 (2022). DOI: 10.1038/s41467-022-32642-0 — https://www.nature.com/articles/s41467-022-32642-0

• NASA, “NASA Achieves Water Recovery Milestone on the International Space Station” — https://www.nasa.gov/missions/station/iss-research/nasa-achieves-water-recovery-milestone-on-international-space-station/

• NASA Technical Reports Server, “Status of ISS Water Management and Recovery,” ICES 2024-317 — https://ntrs.nasa.gov/api/citations/20240005472/downloads/ICES%202024-317%20Status%20of%20ISS%20Water_Final.pdf

• B. M. Marriott (ed.), Nutritional Needs in Hot Environments, National Academies Press (sweat-rate data) — https://www.ncbi.nlm.nih.gov/books/NBK236237/

• K. Brandis, Fluid Physiology, “Insensible Water Loss” — https://med.libretexts.org/Bookshelves/Anatomy_and_Physiology/Fluid_Physiology_(Brandis)/03:_Water_Balance/3.02:_Insensible_Water_Loss

• “How much water is lost during breathing?” PubMed 22714078 — https://pubmed.ncbi.nlm.nih.gov/22714078/

• Ostermann et al., “Management of oliguria,” Intensive Care Medicine (2022). DOI: 10.1007/s00134-022-06909-5 (obligatory minimum urine volume) — https://link.springer.com/article/10.1007/s00134-022-06909-5

• Merck Manual, “Water and Sodium Balance” — https://www.merckmanuals.com/professional/nephrology/fluid-metabolism/water-and-sodium-balance

• Engineering Toolbox, “Water — Heat of Vaporization vs. Temperature” — https://www.engineeringtoolbox.com/water-properties-d_1573.html

• Deranged Physiology, “Mechanisms for heat transfer” (~100 W metabolic heat) — https://derangedphysiology.com/main/cicm-primary-exam/thermoregulation/Chapter-111/mechanisms-heat-transfer

• “Heat Balance in the Human Body,” UBC Physics — https://c21.phas.ubc.ca/article/heat-balance-in-the-human-body-2/

• “Here’s one way to burn less fossil fuel,” The Conversation (exercise heat output) — https://theconversation.com/heres-one-way-to-burn-less-fossil-fuel-use-human-energy-to-heat-buildings-instead-181525

• A. P. Raman, M. A. Anoma, L. Zhu, E. Rephaeli, S. Fan, “Passive radiative cooling below ambient air temperature under direct sunlight,” Nature 515, 540–544 (2014). DOI: 10.1038/nature13883 — https://www.nature.com/articles/nature13883

• H. J. Goldsmid, “Improving the thermoelectric figure of merit,” Science and Technology of Advanced Materials (2021). DOI: 10.1080/14686996.2021.1903816 — https://www.ncbi.nlm.nih.gov/pmc/articles/PMC8049463/

• “What Is a Peltier? Thermoelectric Cooling Explained” (real-world Peltier COP figures) — https://scienceinsights.org/what-is-a-peltier-thermoelectric-cooling-explained/

A note on the estimates: the sweat, respiration, urine, latent-heat, metabolic-heat, and thermoelectric figures are all directly sourced above. The daily electrical-energy (~5 kWh) and battery-mass (~20 kg) figures in “The wall” are my own order-of-magnitude calculations built from those sourced numbers, and are labelled as estimates in the text.
